CDM-570/570L Satellite Modem with Optional IP Module
Appendix K
To control whether or not the ODU provides LNA POWER via the Receive RF Cable:
Use the ◄ ► arrow keys to select ON or OFF, and then press ENTER.
(ODU: Enable) KST CONFIG: KST RX
LNA Fault Logic: Summary
No-Summary
To control whether or not an LNA fault will activate the SUMMARY FAULT
RELAY: Use the ◄ ► arrow keys to select Summary or No-Summary, and then
press ENTER.
(ODU: Enable) KST CONFIG: KST RX
Calibrate LNA Current?
Cal
Calibration allows the system to determine nominal LNA power consumption. This
need only be performed at initial installation.
Use the ◄ ► arrow keys to select Cal or Exit, and then press ENTER.
(ODU: Enable) KST CONFIG: KST RX
LNB:
Calibrate Band
Use the ◄ ► arrow keys to select State, Fault-Logic, Calibrate, or Band, and then
press ENTER.
(ODU: Enable) KST CONFIG: KST RX
(ODU: Enable) KST CONFIG: KST RX
(ODU: Enable) KST CONFIG: KST RX
The State, Fault-Logic, and Calibrate commands operate identically to those used
for the LNA (KST-2000A) unit.
Additionally:
(ODU: Enable) KST CONFIG: KST RX
LNB Rx Band:
A
Use the ◄ ► arrow keys to select A, B, or C, and then press ENTER.
(ODU: Enable) KST CONFIG: Misc (Miscellaneous)
KST MISC: AGC Ref-Adjust
Use the ◄ ► arrow keys to select AGC or Ref-Adjust, and then press ENTER.
(◄ ►,ENT)
Exit (◄ ►,ENT)
State Fault-Logic
◄ ►,
( ENT)
B C (◄ ►,ENT)
(◄ ►,ENT)
LNA
LNA
LNB
(Displayed when ODU is KST-2000B unit)
LNB
LNB
LNB
LNB
(Displayed when ODU is KST-2000B unit)
K–18
Revision 12
MN/CDM570L.IOM
Fault-Logic
Calibrate
State
Fault-Logic
Calibrate
Band
