CDM-570/570L Satellite Modem with Optional IP Module

Installation and Startup

The demod should synchronize, and the Rx TRAFFIC LED indicator on the front panel should

illuminate green.

If the unit does not pass this test, call Comtech EF Data Customer Support for further assistance.

Connecting External Cables

Once the desired configuration settings have been made, and proper operation has been verified

using the IF Loopback test mode, proceed to connect all external cables to the connectors outlined

in the next chapter (Chapter 3. REAR PANEL CONNECTORS

difficulties occur, call Comtech EF Data Customer Support for assistance.

MN/CDM570L.IOM

PINOUTS). Should
