CDM-570/570L Satellite Modem with Optional IP Module
Appendix K
K.3.3.1.1.1 ODU (Transceiver Control): Enable
Select ODU System Type:
Standalone 1:1 (
◄ ►
Use the
following:
•
Select Standalone when the modem is linked via the Rx IF cable to a single Comtech EF
Data CSAT-5060 ODU.
•
Select 1:1 when the modem is linked to a redundant CSAT-5060 system via connection
between the Rx IF and the ODU Redundancy Controller Box.
When the following menu selections are made:
The user is directed to a common ODU SELECT submenu branch:
ODU SELECT: Config
Monitor
For clarity, this common submenu branch is defined in detail in Sect. K.3.3.1.1.1.1.
(ODU: Enable) Standalone
ODU SELECT: Config
Monitor Alarms (
Use the ◄ ► arrow keys to select Config, Info, Monitor, or Alarms, and then press ENTER. The
selections for this common submenu branch are defined in detail in Section K.3.3.1.1.1.1.
(ODU: Enable) 1:1
Monitor/Control:
CSAT#2 Red-Box (
For monitor/control of a redundant CSAT-5060 system: Use the
CSAT#1, CSAT#2, or Red-Box, and then press ENTER.
(ODU: Enable) 1:1
ODU SELECT: Config
Monitor
Use the ◄ ►
The selections for this common submenu branch are defined in detail in Sect. K.3.3.1.1.1.1.
◄ ►,
ENT)
arrow keys to select Standalone or 1:1, and then press ENTER. Note the
ODU Transceiver Control: Enable
ODU Transceiver Control: Enable
ODU Transceiver Control: Enable
Alarms (◄ ►,ENT)
Info
◄ ►
,ENT)
CSAT#1
◄ ►,
ENT)
CSAT#1 or CSAT#2
Info
◄ ►
Alarms ( ,ENT)
arrow keys to select Config, Info, Monitor, or Alarms, and then press ENTER.
Standalone
1:1 CSAT#1
1:1 CSAT#2
Info
K–6
Revision 12
MN/CDM570L.IOM
◄ ► arrow keys to select
