CDM-570/570L Satellite Modem with Optional IP Module
Ethernet IP Module - CLI and Telnet Operation

Administration Page

Activate the Administration page from the Main Menu page.
Access to the Administration page is restricted to the Admin user when
connecting via the Telnet, or HTTP interface. The Administration page is available
when connected via the Terminal Emulator (serial) connection because there is
no login.
The Administration page contains the following options/fields:
Selection
Name/Password
Configuration
Access Lists
Feature Configuration
3xDES Configuration
SMTP Configuration
SNMP Configuration

Figure 14-2. Administration page

Entry Description
Displays the Name/Password Configuration page. Defines the user name
P and passwords that are required in order to access the management
interfaces.
Displays the Access Lists page. Use this to restrict access to the
A
management interfaces based upon the requester's IP address.
F Displays the Feature Configuration page.
Determines if 3xDES encryption is enabled on a device, and if so, the
3xDES keys that is used to decrypt traffic. The keys specified for the
D
transmit function are completely independent for the 3xDES keys specified
for the receiver function.
M Specifies SMTP email server settings.
N Specifies SNMP management parameters.
14–4
Revision 12
MN/CDM570L.IOM
