CDM-570/570L Satellite Modem with Optional IP Module
Introduction
1.4.6

Miscellaneous

Front Panel
Loopbacks
Fault Relays
M&C Interface
Ethernet
M&C Software
Dimensions
Weight
AC Consumption
Operating Voltage
Operating Temperature
Tactile keypad, 6 keys (Up/Down, Left/Right, Enter/Clear)
Vacuum Fluorescent Display (blue) - 2 lines of 24 characters
Internal IF loopback, RF loopback, digital loopback, and inward/outward loopback
Hardware fault, Rx and Tx Traffic Alarms
EIA-232 and EIA-485 (addressable multidrop, 2-wire or 4-wire)
10/100 Base Tx for http:, SNMP and Telnet interfaces
SatMac Ver. 4.7
CDM-570L: 1RU high x 19 inches (482.6 mm) wide x 16 inches (406 mm) deep
CDMR-570L: 1RU high x 19 inches (482.6 mm) wide x 11 inches (279 mm) deep
CDM-570: 1RU high x 19 inches (482.6 mm) wide x 13 inches (330 mm) deep
CDM-570L: 7 lbs (3.2 kg) max (not including BUC Power Supply)
CDMR-570L: 6.4 lbs (2.9 kg) max (not including BUC Power Supply)
CDM-570: 5 lbs (2.3 kg) max
CDM-570L (without BUC Power Supply or IP Module):
29 Watts (typical) 32 Watts (maximum)
CDM-570L when fitted with 150 Watt@50°C, 180 Watt@30°C BUC power supply:
250 Watts (maximum)
CDM-570: (without IP Module):
29 Watts (typical) 32 Watts (maximum)
Typical measured VA, Power Factor and power data:
CDM-570L – no IP Module installed:
240V 50 Hz Power Factor = 0.44, 65VA, 29 Watts
110V 60 Hz Power Factor = 0.55, 50VA, 28 Watts
CDM-570L – with IP Module installed:
240V 50 Hz Power Factor = 0.46, 80VA, 37 Watts
110V 60 Hz Power Factor = 0.56, 63VA, 35 Watts
CDM-570 – no IP Module installed:
240V 50 Hz Power Factor = 0.33, 87VA, 29 Watts
110V 60 Hz Power Factor = 0.53, 51VA, 28 Watts
CDM-570 – with IP Module installed:
240V 50 Hz Power Factor = 0.36, 99VA, 37 Watts
110V 60 Hz Power Factor = 0.54, 64VA, 35 Watts
• Standard AC operation (CDM-570 or CDM-570L only):
100 - 240 volts AC, +6%/-10% – autosensing (total absolute max. range is 90 - 254 volts AC)
• Optional DC Power Supplies available :
48 volt DC (modular for CDM-570 or CDM-570L, terminal block for CDMR-570L)
24 volt DC power supply available (modular, CDM-570 or CDM-570L only)
0 to 50 C (32 to 122 F)
o o
