CDM-570/570L Satellite Modem with Optional IP Module
Ethernet IP Module - CLI and Telnet Operation
14.2.7

Vipersat Configuration Page

This page is displayed only if the optional Vipersat feature is enabled.
Activate the Vipersat Configuration page from the Main Menu page.
The Vipersat Configuration page contains the following options/fields:
Selection
STDMA Mode
Automatic Switching
Unit Role
Expansion Unit
Bandwidth Group ID
Unit Name
Multicast Management IP
Address
Multicast VMS Management IP
Address
Managing IP Address
Path Loss Data Multicast
(PLDM)
Dynamic Power Control Config
Set Home State Parameters

Figure 14-23. Vipersat Configuration page

Entry Description
T
A
R
E
B
N
Used only when CDM-570/570L is used in a Vipersat system.
M
Refer to the Vipersat User Manual for complete information.
V
I
P
C
H
14–36
Revision 12
MN/CDM570L.IOM
