CDM-570/570L Satellite Modem with Optional IP Module
Appendix E
E.5.8.4 Quality of Service (QoS) Statistics Commands and Queries
Command Arguments for
Parameter (Instruction Command or
Type Code and Response to
Qualifier)
Quality of Service N/A String of QoS
Statistics Get Stats
Quality of Service QSC=xx xx – QoS rule
Stats Clear xx = QoS rule index for which to
index clear stats.
Clear All QoS QSA= QSA=x
Queue Statistics
1 – Clear all stats
Description of Arguments
Query
Query only.
Displays the QoS queue statistics of all active queues.
nnn|pp|aaaaaaaaaa|bbbbb|cccccccccc|dddddddddd|eeeeeeeeee|fffff|ggggg|h
hhhh|iiii
n – QoS Rule Number
p – Protocol number [Refer to QSR]
a – Sent Packets
b – Pkts per Second
c – Sent Bytes
d – Dropped Packets
e – Dropped Bytes
f – Current Transmit Rate [Kbps]
g – Average Transmit Rate [Kbps]
h – Maximum Transmit Rate [ Kbps]
I – Active Flow count associated with this QoS Queue.
>0001/QST=
0|19| 0| 0| 0|
1| 0| 0| 0| 0|
Command only.
Clears the QoS statistics for a specified queue. The command can be issued
only on active/configured queue. To clear default queue stats use '0'.
<1/QSC=0 will clear default queue stats
<1/QSC=5 will clear stats of rule-5.
Command only.
Setting QSA=1 will clear all QoS queue statistics. Also clears the default
queue stats.
0| 0| 0| 0| 0| 0chr(13)
0| 0| 0| 0| 0| 0chr(13)
E–31
MN/CDM570L.IOM
Query
Response to (Instruction
Response to Query
Command Code and
Qualifier)
QST! QST? QST=sssssssss...
String displaying QoS stats of
all active queues.
\r – CR – 0x0D
\n – Newline – 0x0A
QSC= N/A QSC=xx
QSC!
(see description of argument)
QSA= N/A QSA=x
QSA!
(see description of argument)
Revision 12
