CDM-570/570L Satellite Modem with Optional IP Module
Appendix E
Command
Parameter (Instruction
Type Code and
Response to Query
Qualifier)
TX Payload TPE= 1 byte, value of 0, 1,
Compression 2 or 3
enable/disable
3xDES Encrypt Key DEK[1..8]= 48 bytes, numerical
3xDES Decrypt Key DDK[1..8]= 48 bytes, numerical
SMTP Server IP SIA= 15 bytes,
Address numerical
SMTP Domain SDM= 128 bytes,
Name characters, no
spaces
SMTP Destination SDN= 128 bytes,
Name characters,
SNMP SRC= 255 bytes,
Read Community characters, no
spaces
Arguments for
Command or
Command or Query, where:
0=Disabled
1= Enabled (Managed Switch Only mode)
2 = PerRoute (read-only when FAST feature is purchased in
mode)
3 = Unavailable (read-only when FAST feature not purchased)
Acts as command, only in Managed Switch mode. In router mode, it's read-only.
Enables or disables the Transmit 3xDES feature.
Restriction: Cannot enable if the 3xDES FAST feature has not been purchased
Command or Query.
3xDES encrypt key [192-Bit], where all are Hexadecimal digits. [0...F], a total of
48 Hex digits.
Example: DEK[1]= 222222222222222244444444444444446666666666666666
Command or Query.
3xDES decrypt key, where all are Hexadecimal digits. [0...F], a total of 48 Hex
digits.
Example: DDK:0= 222222222222222244444444444444446666666666666666
Command or Query.
Used to set the IP address of the SMTP server where mail should be sent, in the
format:
xxx.xxx.xxx.xxx is the IP address
Example: <1/SIA=010.006.030.001.
When not configured, it returns >0001/SIA=0.0.0.0
Command or Query.
SMTP Domain name of up to 128 characters. To delete the domain name, issue
<1/SDM=
Empty string will delete the domain name.
Example: SMTP=somedomainname
Command or Query.
SMTP Destination name of up to 128 characters. To delete the destination name,
issue <1/SDN=
Empty string will delete the domain name.
Example: <1/SMTP=somedestinationname
Command or Query.
SNMP read community string. Empty string is not allowed
Example: <1/SRC=public
Description of Arguments
E–13
Query
Response to
(Instruction Code
Command
and Qualifier)
TPE = TPE?
TPE!
router
DEK = DEK[1..8]?
DEK!
DDK = DDK[1..8]?
DDK!
SIA = SIA?
SIA!
SDM = SDM?
SDM!
SDN = SDN?
SDN!
SRC = SRC?
SRC!
Revision 12
MN/CDM570L.IOM
Response to
Query
TPE =x
(see description of
arguments)
DEK= x [1..48]
(see description of
arguments)
DDK =x [1..48]
(see description of
arguments)
SIA =
xx.xxx.xxx.xxx (see
description of
arguments)
SDM =x [1..128]
(see description of
arguments)
SDN =x [1..128]
(see description of
arguments)
SRC =x
(see description of
arguments)
