CDM-570/570L Satellite Modem with Optional IP Module
Ethernet IP Module - CLI and Telnet Operation
Selection
Tx Modulation
Tx Spectrum Inversion
Tx Data Inversion
Tx Scrambling
Tx Output Power
Tx Carrier
Tx Clock Source
Entry Description
Sets transmit modulation type
M
1 – BPSK
2 – QPSK
3 – OQPSK
4 – 8-PSK
5 – 16-QAM
6 – 8-QAM
1 – Normal
U
2 – Inverted
1 – Normal
I
2 – Inverted
1 – Off
B
2 – On-Default
3 – On-IESS-315
P
Valid ranges are from 0.0 to 40.0 dBm (minus sign assumed)
1 – OFF
C
2 – ON
3 – Rx-Tx Inhibit (turns off the transmitter if the Rx is not locked)
NOTE: In a 1:1 Redundant system, the standby modem will display
[External Control].
[Internal]
14–40
Revision 12
MN/CDM570L.IOM
