Comtech EF Data CDM-570 Installation And Operation Manual page 472

CDM-570/570L Satellite Modem with Optional IP Module
Appendix K
(ODU SELECT) ODU CONFIG: ODU RX
ODU Rx Slope Mode:
Manual
Use the
(ODU SELECT) ODU CONFIG: ODU RX
ODU Rx Slope:
0.0
Use the
(ODU SELECT) ODU CONFIG: Misc
MISC: Cold-Start AFR LNA
XRef Ref-Adjust RTC (◄ ►)
Use the ◄ ► arrow keys to select Cold-Start, AFR, LNA, XRef, Ref-Adjust, or RTC, and
then press ENTER.
(ODU SELECT) ODU CONFIG: MISC
Cold-Start State:
Enabled
Use the ◄ ► arrow keys to select Enabled or Disabled, and then press ENTER.
(ODU SELECT) ODU CONFIG: MISC
Auto Fault Recovery:
Enabled
Use the ◄ ► arrow keys to select Enabled or Disabled, and then press ENTER.
(ODU SELECT) ODU CONFIG: MISC
LNA: State
Cal Fault-Logic (◄ ►,ENT)
Use the ◄ ► arrow keys to select State, Curr-Window, Cal, or Fault-Logic, and then
press ENTER.
(ODU SELECT) ODU CONFIG: MISC
ODU LNA State:
On
To control whether or not the CSAT provides LNA POWER via the Receive RF
Cable: Use the ◄ ► arrow keys to select On or Off, and then press ENTER.
Calibrated
◄ ► arrow keys select Manual or Calibrated, and then press ENTER.
▲ ▼,
(
▲ ▼ arrow keys to edit the ODU Rx Slope setting, and then press ENTER.
Disabled (◄ ►)
Disabled (◄ ►)
Curr-Window
Off (◄ ►,ENT)
Slope
(◄ ►)
Slope
ENT)
Cold-Start
AFR (Auto Fault Recovery)
LNA
LNA
K–10
Revision 12
MN/CDM570L.IOM
Manual
State
