CDM-570/570L Satellite Modem with Optional IP Module
Ethernet IP Module - CLI and Telnet Operation
14.2.11.1 Unit Information Page
Activate the Unit Information page from the Operations and Maintenance page.
The Unit Information page displays the following information:
Info Set Item
1 Current System time
Image # that the IP Module is
currently booted from
Image # that the base modem is
2
currently booted from.
PARAM file that the IP Module is
currently configured from
Currently Loaded IP Module and
Base Modem SW:
3
EVENTLOG
PARAM

Figure 14-36. Unit Information page

•
Boot
•
IP Bulk #1
•
IP Bulk #2
•
BaseBoot
•
Base Bulk #1
•
Base Bulk #2
Description
DAY MONTH DATE hh:mm:ss YEAR
By default displays Latest, unless "IP Module Boot From" is
set to Image #1 or Image #2
By default displays Latest, unless "Base Modem Boot From" is
set to Image #1 or Image #2
Displays PARAM file from Flash or Factory Default if no
parameter file is found in flash memory.
Displays Build Date, CEFD FW#, Revision #, and size of each
IP Module and Base Modem SW file:
•
Boot file for the IP Module and the Base Modem.
•
Bulk file contains all of the SW files for the IP Module
and Base Modem and there are two slots available.
Displays the date/time that the EVENTLOG file was last
updated.
Displays the date/time that the PARAM1 file was last updated.
Also shows what user interface was used to last update the
PARAM file.
•
From CLI, displays 'console'
•
From Web, displays 'http'
•
From Telnet, displays the Telnet user login name
•
From SNMP, displays 'snmp'
