CDM-570/570L Satellite Modem with Optional IP Module
Appendix E
Command
Parameter (Instruction
Type Code and
Qualifier)
DiffServ Table Get N/A String of DiffServ
Table
QoS Rule QSR= QSR[0..32]=
Index-0 is the
default rule
Arguments for
Command or
Response to
Query
Query only.
Displays the complete Diffserv rules. Can be issued when QoS mode is set in Diff
Serv. There are 12-rows/rules. Each rule is separated by chr(13).
>0001/DTG=chr(13)
EXFD|101 110|00000|99999|1chr(13)
CLS1|001 000|00000|99999|1chr(13)
CLS2|010 000|00000|99999|2chr(13)
CLS3|011 000|00000|99999|3chr(13)
CLS4|100 000|00000|99999|4chr(13)
CLS5|101 000|00000|99999|5chr(13)
CLS6|110 000|00000|99999|6chr(13)
CLS7|111 000|00000|99999|7chr(13)
ASF1|001 xx0|00011|01111|8chr(13)
ASF2|010 xx0|00022|02222|8chr(13)
ASF3|011 xx0|00000|99999|8chr(13)
ASF4|100 xx0|00000|99999|8chr(13)chr(10)
Command or Query.
QSR=tt|p|sss.sss.sss.sss/ss|ddd.ddd.ddd.ddd/dd|AAAAA|BBBBB|CCCCC|DDDDD|
mmmmm|MMMMM|w|f
Where t = Protocol Type:
01 - UDP 02 - TCP 03-ICMP
04-RTP 05-VOCE 06-VDEO
07-RTPS
08-FTP 09-HTTP 10-TELN 11-SMTP
12-SNMP 13-SAP 14-ORCL
15-CTRX 16-SQL 17-IP 18 for N-IP
19-ALL [Valid only for default rule]
Where p =
PRI=1..8 (only applies in max/priority mode). In Min/Max mode priority for all rules
is fixed at 8. User should not be allowed to change priority in Min/Max mode.
Priority-9 is being used for default rule, and obtained from PARAM file. Pri-9 cannot
be used for configuring other rules.
Where s = Source IP
SIP=xxx.xxx.xxx.xxx/yy [yy – subnet mask]. All '*' signifies all IP address
range[***.***.***.***/**].
Where d = Destination IP
DIP=xxx.xxx.xxx.xxx/yy [yy – subnet mask]. All '*' signifies all IP address range, like
[***.***.***.***/**]
All '*' signifies all port range of 00000 – 65535 for TCP/UDP.
All port numbers should in fixed length of 5-chars
Description of Arguments
E–18
Revision 12
MN/CDM570L.IOM
Query
Response to
(Instruction Code
Command
and Qualifier)
DTG= DTG? DTG=sssss.....ss
DTG!
Display all 12
Diffserv rules.
QSR = QSR[0..32]? QSR[0..32] =
QSR! Index-0 is the See description.
default rule Index-0 is the
default rule
Response to
Query
