Enable / Disable Demo Mode - Comtech EF Data CDM-570 Installation And Operation Manual

CDM-570/570L Satellite Modem with Optional IP Module
Appendix C
C.2.5

Enable / Disable Demo Mode

Demo Mode allows access to ALL CDM-570/570L FAST options for 604800 seconds (7 full
days).
Control FAST Demo Mode as follows:
a) Press CLEAR to return to the UTIL: FAST submenu:
b) From the UTIL: FAST submenu, use the ◄ ► arrow keys to select Cnfg, and then press
ENTER.
c) From the FAST Configuration screen, use the ◄ ► arrow keys to select to select Demo
Mode, and then press ENTER.
d) Use the ◄ ► arrow keys to select FAST Demo Mode as Off or On, and then press
ENTER.
When On, the bottom line displays the number of available seconds remaining for the
free Demo Mode. During this time, Demo Mode may be turned on and off an unlimited
number of times until the 604800 seconds have expired. The available time decrements
only when Demo Mode is On.
When the Demo period expires, the following message displays:
FAST:Cnfg View (H/W 0.03)
MainBoard S/N: 123456789
FAST Configuration:
Edit Code Demo Mode
FAST Demo Mode: Off
604800 seconds remain
FAST Demo Mode: Off
Demo Period Expired
IF THE DEMO MODE STATE (OFF/ON) IS CHANGED, OR IF DEMO MODE IS
ENABLED AND THE TIMER EXPIRES, THE MODEM FIRMWARE WILL
AUTO-REBOOT AFTER 5 SECONDS.
NOTE THAT VALIDATION OF AUTHORIZED FAST OPTIONS OCCURS ON
AUTO-REBOOT; IF AN INVALID CONFIGURATION IS FOUND, THE MODEM
CONFIGURATION WILL RESET TO DEFAULT VALUES.
On
On
C–4
Revision 12
MN/CDM570L.IOM
