CDM-570/570L Satellite Modem with Optional IP Module
Front Panel Operation
Demod: Not Locked
Press ENTER or CLEAR to return to the previous menu.
5.2.2.2.3

MONITOR: Event-Log (Stored Events)

Stored Events:
Clear-All
Use the ◄ ► arrow keys to select View or Clear-All, and then press ENTER.

5.2.2.2.3.1 (MONITOR: Stored Events) View

Log23: 30/11/02 10:37:32
Fault - Demod Lock (▲ ▼)
When a fault condition occurs, it is time-stamped and put into the Stored Events Log. This log
can store up to 255 events. Similarly, when the fault condition clears, this is also recorded, as
shown per the following example:
Log240:30/11/97 10:37:35
Clear - Demod Lock (▲ ▼)
Use the arrow keys to scroll backwards or forwards through the log entries. Press ENTER
▲ ▼
or CLEAR to return to the previous menu.

5.2.2.2.3.2 (MONITOR: Stored Events) Clear-All

Clear all Stored Events?
No Yes
Use the ▲ ▼ arrow to choose No or Yes, and then press ENTER. If Yes is selected, the event log
is cleared and the previous menu is displayed. However, if faults are present on the modem at this
time, they are re-time-stamped and new log entries are generated.
Note that in accordance with European convention, the date is shown in DAY-
MONTH-YEAR format.
5.2.2.2.4

MONITOR: Stats (Link Statistics)

Link Statistics:
Clear-All Config(◄ ►,ENT)
Use the ◄ ► arrow keys to select View, Clear-All, or Config, and then press ENTER.
RSL=-64
View
(◄ ►,ENTER)
(▲ ▼, ENTER)
View
5–36
Revision 12
MN/CDM570L.IOM
