Comtech EF Data CDM-570 Installation And Operation Manual page 479

CDM-570/570L Satellite Modem with Optional IP Module
Appendix K
(ODU: Enable) KST CONFIG: KST TX
HPA Fault Logic: Summary
No-Summary
To control whether or not HPA fault will activate the SUMMARY FAULT RELAY:
Use the ◄ ► arrow keys to select Summary or No-Summary, and then press
ENTER.
(ODU: Enable) KST CONFIG: Receiver
KST RX: Frequency
LNA
KST RX: Frequency
LNB
Use the ◄ ► arrow keys to select Frequency, Atten, or LNA/LNB, and then press ENTER.
(ODU: Enable) KST CONFIG: KST RX
ODU Rx Frequency:
10950.0 MHz (◄ ►,▲ ▼,ENT)
To edit the receive frequency: First, use the
then use the
(ODU: Enable) KST CONFIG: KST RX
ODU Rx Attenuation:
15 dB
To edit the receive attenuation: First, use the
then use the
(ODU: Enable) KST CONFIG: KST RX
LNA:
Calibrate
Use the ◄ ► arrow keys to select State, Fault-Logic, or Calibrate, and then press
ENTER.
(ODU: Enable) KST CONFIG: KST RX
ODU LNA State:
On
If the HPA power is Off, it cannot report errors, answer messages,
provide serial numbers, etc.
(◄ ►,ENT)
Atten
◄ ►,E
( NT)
Atten
◄ ►,E
( NT)
▲ ▼ arrow keys to change the value of that digit. Press ENTER when done.
◄ ►,▲ ▼,
(
▲ ▼ arrow keys to change the value of that digit. Press ENTER when done.
State Fault-Logic
◄ ►,
( ENT)
Off (◄ ►,ENT)
HPA
(Displayed when ODU is KST-2000A unit)
(Displayed when ODU is KST-2000B unit)
Frequency
◄ ► arrow keys to select a digit to edit, and
Atten (Attenuation)
ENT)
◄ ►
arrow keys to select a digit to edit, and
LNA
(Displayed when ODU is KST-2000A unit)
LNA
K–17
Revision 12
MN/CDM570L.IOM
Fault-Logic
State
