CDM-570/570L Satellite Modem with Optional IP Module
Ethernet IP Module Interface

13.4 IP Module Optional Features

Enhancing the IP Module performance is simple. Additional features can be quickly added on site
by using the CDM-570/570L front panel controls to enter a FAST Access Code purchased from
Comtech EF Data. See Appendix C. FAST ACTIVATION PROCEDURE for more
information.
•
3xDES Data Encryption
•
IP Header Compression
•
Payload Compression
•
Quality of Service (QoS) – supports three different modes of QoS:
o Minimum/Maximum Bandwidth
o Maximum Bandwidth/Priority
o DiffServ (Differentiated Services)
•
Vipersat (Management by VMS)
•
VFS (Vipersat File Streaming).
13.4.1

CDM-570/570L IP Module Demo Mode

Demo Mode temporarily enables the following IP optional features:
•
IP Header Compression
•
Payload Compression
•
Quality of Service (QoS)
•
Vipersat
•
VFS
The Demo Mode is a cumulative counter that can be stopped and started at any time, for a total
time duration of up to seven (7) days, or 168 hours.
To enable Demo Mode: From the CDM-570/570L front panel, select UTIL: DEMO
The seven day Demo Mode Timer will start but can be stopped at any time by setting Demo
Mode to OFF.
All IP FAST Options except 3xDES Encryption may be temporarily enabled using
the 7-day Demo Mode.
13–8
Revision 12
MN/CDM570L.IOM
ON.
