CDM-570/570L Satellite Modem with Optional IP Module
Front Panel Operation

5.2.2.1.9.4 (CONFIG: Alarm Mask) BUC (CDM-570L ONLY)

See Appendix L. CDM-570L ODU (BUC, LNB) OPERATION for complete details
about using this modem-specific menu branch.
BUC Alarm:
Active Masked (◄ ►,ENT)
For the CDM-570L only: Use the
Converter), if connected, as Active or Masked.

5.2.2.1.9.5 (CONFIG: Alarm Mask) LNB (CDM-570L ONLY)

See Appendix L. CDM-570L ODU (BUC, LNB) OPERATION for complete details
about using this modem-specific menu branch.
LNB Alarm:
Active Masked (◄ ►,ENT)
For the CDM-570L only: Use the
Block Down Converter), if connected, as Active or Masked.
5.2.2.1.10

CONFIG: ODU (CDM-570L ONLY)

See Appendix L. CDM-570L ODU (BUC, LNB) OPERATION for complete details
about using this modem-specific menu branch.
ODU (Outdoor Unit):
BUC LNB
For the CDM-570L only: Use the
or LNB (Low-Noise Block Down Converter), if connected.
◄ ► arrow keys to set the alarm for the BUC (Block Up
◄ ► arrow keys to set the alarm for the LNB (Low-Noise
(◄ ►,ENTER)
◄ ►
arrow keys to configure a BUC (Block Up Converter)
5–33
Revision 12
MN/CDM570L.IOM
