CDM-570/570L Satellite Modem with Optional IP Module
Updating Firmware
4.3

Preparation for the Base Modem Ethernet FTP Upload Procedure

Step Task
1 Identify the product in use, its firmware number for download, and its version number.
The current modem M&C version and/or firmware number can be viewed as follows:
•
Via the front panel: The firmware version is available from the VFD's top-level
screen. To view this screen, press the [CLEAR] key several times.
The firmware number can also be found within the SELECT: UTIL
Info
•
Via serial remote control: The firmware number, versions, and revision level can
be queried as follows:
•
Via the Base Modem Web Server Interface: The Bootrom, Bulk1 and Bulk2
firmware loads may be viewed after selecting the Unit Info hyperlink (available
under the Maint [Maintenance] page tab). For more information, refer to Chapter 7.
BASE MODEM WEB SERVER INTERFACE.
2 Create a temporary directory (folder) on the PC:
Windows: Select File
unused name. A "c:\temp" folder should now exist.
Note: The c: is the drive letter used in this example. Any valid, writable drive letter can be
used.
CMD prompt: At the command prompt (c:\>) type "MD temp" or "mkdir temp" without quotes
(MD and mkdir stand for make directory). A "c:\temp" subdirectory should now exist, where
c: is the drive letter used in the example.
3 Download the correct firmware file to this temporary folder:
a) Go online to www.comtechefdata.com.
b) On the Main page – under Support Information or the Support tab, select the
Software Downloads hyperlink.
c) On the Software Downloads page – click Download Flash and Software Update
Files.
d) On the Flash Updates Index page – select the (Select a Product Line) Modems
hyperlink.
e) On the Modems product page – select the CDM-570 and CDM-570L product
hyperlink.
f) Select the appropriate firmware EXE or ZIP download hyperlink.
Refer to the table in Sect. 4.2 About Firmware Numbers, File Versions, and Formats in
this chapter for the naming and availability of the firmware download hyperlinks, archive files,
and downloaded image files.
Image#1 or Image#2 menu branches.
Abbreviated: <0/SWR?
New Folder and rename the "New Folder" to "temp" or another
Detailed: <0/FRW?
or:
4–3
Revision 12
MN/CDM570L.IOM
Firmware
