Appendix F. IP QUICK-START
F.1

Quick-Start Guide Introduction

This appendix serves to guide the user through the steps needed to pass IP traffic within minutes
of initial installation and setup (i.e., starting from factory default settings), using a pair of CDM-
570/570L modems equipped with the optional IP Module Ethernet Interface. These modems are
generically referred to through the remainder of this appendix as the CDM-IP. This appendix
assumes operator familiarity with configuration of the base modem.
F.2

Getting Started

F.2.1 Equipment List
The following equipment is required:
Description
CDM-IP Modem
Layer 2 Ethernet Switch
PC with network interface card
(NIC) and a terminal emulation
program
Console cable (DB-9 to RJ-11)
Ethernet cables (CAT5)
IF cables
Qty Comments
2 CDM-570/570L w/ IP Module, CDM-IP 550, and CDM-IP 300L.
Note: You may need to provide equipment to convert 70 MHz IF to
L-Band for a duplex connection depending upon modems.
2 User-supplied.
RJ-45 crossover Ethernet cables can be substituted to directly connect
PC to CDM-IP modem without the use of a hub.
2 User-supplied.
1 Supplied by Comtech EF Data.
4 User-supplied.
2 User-supplied to interconnect Tx-Rx between both CDM-IP modems.
F–1
GUIDE
