CDM-570/570L Satellite Modem with Optional IP Module
Appendix L
L.3.3.2 (SELECT:) Monitor
MONITOR: Alarms Rx-Params
Event-Log Stats AUPC ODU
For ODU operation, use the
L.3.3.2.1 MONITOR: Alarms
Live Alarms:Unit Receive
Transmit ODU (◄ ►,ENTER)
The CDM-570L uses a system of Fault Prioritization. This system cuts down
significantly on unwanted and irrelevant fault reporting. In each category of fault,
only the highest priority fault is displayed. For example, if the demodulator is
unlocked, it is irrelevant if there are other receive faults present. If the demodulator
then locks, but there is a fault of a lower priority present, this will then be
displayed. This also holds true for the faults reported via the remote control.
ODU Status
For ODU Live Alarms, use the
L.3.3.2.1.1 (MONITOR: Live Alarms) ODU
ODU Alarms: BUC Current
Out of Limits
ODU Alarms: None
This read-only screen indicates if there are any ODU Alarms present. If a prioritized fault is
present it is displayed here (as per the SUMMARY OF PRIORITIZED ODU FAULTS table).
If not, the screen displays '
Press ENTER or CLEAR to return to the previous menu.
◄ ► arrow keys to select Alarms or ODU, and then press ENTER.
SUMMARY OF PRIORITIZED ODU FAULTS
1) BUC PLL lock fault
2) BUC Current Out of Limits
3) BUC Voltage Out of Limits
4) LNB Current Out of Limits
5) LNB Voltage Out of Limits
6) BUC Temperature Alarm
7) BUC Software Checksum Error
◄ ► arrow keys to select ODU, and then press ENTER.
(ENT)
(ENT)
None
'.
L–10
Revision 12
MN/CDM570L.IOM
