CDM-570/570L Satellite Modem with Optional IP Module
Appendix D
Command Arguments for
Parameter (Instruction Command or
Type Code and Response to
Qualifier)
Global
Configuration
(cont.)
D.6.5

BUC Commands and Queries (CDM-570L ONLY)

Command
Parameter (Instruction
Type Code and
Qualifier)
BUC Address BAD=
BUC Comms BCE=
enable
BUC High Current BCH=
Limit
Description of Arguments
Query
R=RTS/CTS Control
S = Statistics Sampling Interval
T = Attach BUC Alarm to Tx Alarm
U = Attach LNB Alarm to Rx Alarm
VVVVVV = expansion bytes
V = number of Tx channels for WAd
W = number of Rx channels for WAd
YYYY = expansion bytes
Fill unused expansion bytes with 'x'
Arguments for
Command or
Response to
Query
2 byte, Command or Query.
value of 01 to 15
Indicates the BUC Address, in the form xx, where:
xx = between 01 and 15.
Example: BAD=03
1 byte, Command or Query.
value of 0 or 1
Enables or disables communications, via the FSK link, with an externally connected
Block Up Converter (BUC), where:
0=Disabled
1=Enabled
Example: BCE=0 (Disabled)
4 bytes Command or Query.
BUC High Current Limit, in mA, the form xxxx, where:
xxxx = between 500 and 4000
Example: BCH=3100
same as RTS
same as SSI
same as ABA
same as ALA
Description of Arguments
D–31
MN/CDM570L.IOM
Query
Response to (Instruction
Response to Query
Command Code and
Qualifier)
Query
Response to
(Instruction Code
Command
and Qualifier)
BAD = BAD?
BAD?
BAD *
BAD #
BCE= BCE?
BCE?
BCE*
BCE#
BCH= BCH?
BCH?
BCH*
BCH#
Revision 12
Response to
Query
BAD=xx
(see Description of
Arguments)
BCE=x
(see Description of
Arguments)
BCH=xxxx
(see Description of
Arguments)
