Comtech EF Data CDM-570 Installation And Operation Manual page 382

CDM-570/570L Satellite Modem with Optional IP Module
Appendix D
Command
Parameter (Instruction
Type Code and
Qualifier)
BUC Low Current BCL= 4 bytes
Limit
BUC Current N/A 4 bytes
BUC Voltage N/A 4 bytes
BUC 10 MHz BFR= 1 byte,
Reference value of 0 or 1
BUC LO Frequency BLO= 6 bytes
BUC Output BOE= 1 byte,
Enable value of 0 or 1
BUC Output Power N/A 4 bytes
Level
Arguments for
Command or
Response to
Query
Command or Query.
BUC Low Current Limit, in mA, the form xxxx, where:
xxxx = between 0 and 3000
Example: BCL=0600
Query only.
BUC Current, in mA, in the form xxxx, where:
xxxx = between 0 and 9999
If not available, response is 0000.
Example: BDC=3100
Query only.
BUC Voltage, in the form xx.x, where:
xx.x = between 0 and 64.0
If not available, response is 00.0.
Example: BDV=43.6 (BUC DC voltage is 43.6 volts)
Command or Query.
BUC 10 MHz frequency reference, where:
0 = Disabled
1 = Enabled
Example: BFR=0 (BUC 10MHz reference disabled)
Command or Query.
BUC Tx LO frequency information in the form xxxxxs, where:
xxxxx = LO frequency, in the range of 3000 to 65000 MHz.
All 0's (000000) disables the feature.
s = sign for the mix (+ or - character)
Terminal Frequency = BUC LO ± TFQ
Example: BLO = 12000+ (BUC LO is 12 GHz, low-side mix)
Command or Query.
BUC Output, where:
0 = Off (output disabled)
1 = On (output enabled)
Example: BOE=1 (BUC output is enabled)
Query only.
BUC Output Power Level, in Watts, in the form xx.x.
Returns 00.0 when FSK and BUC power are not enabled.
Example: BOL=08.3 (BUC reports output power is 8.3 Watts)
Description of Arguments
D–32
Revision 12
MN/CDM570L.IOM
Query
Response to
(Instruction Code
Command
and Qualifier)
BCL= BCL? BCL=xxxx
BCL? (see Description of
BCL* Arguments)
BCL#
N/A BDC? BDC=xxxx
(see Description of
Arguments)
N/A BDV? BDV=xx.x
(see Description of
Arguments)
BFR= BFR? BFR=x
BFR? (see Description of
BFR* Arguments)
BFR#
BLO= BLO? BLO=xxxxxs
BLO? (see Description of
BLO* Arguments)
BLO#
BOE= BOE? BOE=x
BOE? (see Description of
BOE* Arguments)
BOE#
N/A BOL? BOL=xx.x
(see Description of
Arguments)
Response to
Query
