CDM-570/570L Satellite Modem with Optional IP Module
Front Panel Operation
5.2.2.4.6

INFO: Intfc (Interface)

This screen displays details for the of the main data port's electrical interface type. If RS422,
V.35, or RS232 is selected, the menu also indicates the operation of RTS/CTS. Examples are as
follows:
Interface: RS422
RTS/CTS Loop, No Action
Interface:G.703 E1-Unbal
HDB3 (ENTER or CLEAR)
Interface: G.703 T1 B8ZS
533-655 feet(ENT or CLR)
Interface: IP
IEEE 802.3 Ethernet
5.2.2.4.7

INFO: Rem (Remote Control)

This screen displays whether the modem is in Local or Remote mode; gives details of the
electrical interface type selected; the unit's address; and the baud rate selected, etc. Examples are
as follows:
Remote M&C: Monitor Only
(Local Control only)
Remote M&C: RS485-4Wire
Address: 0001 19200 Baud
Remote M&C: 100BaseTx
IP Addr: 255.255.255.255
Press ENTER or CLEAR to return to the previous menu.
5.2.2.4.8

INFO: Msk (Alarm Mask)

Mask: FIFO BPV TAIS RAIS
AGC EbNo BUF Ref BUC LNB
This screen displays, in the same format as the CONFIG: Mask submenu, which alarms are
currently masked. If an alarm is not masked, the relevant screen position is replaced with a blank
space.
Note: When in G.703 Clock Extended Mode (CEx), BPV is replaced with LOS to indicate the
alarm mask of G703 Loss of Signal.
(ENT)
(ENT)
5–43
Revision 12
MN/CDM570L.IOM
