CDM-570/570L Satellite Modem with Optional IP Module
Front Panel Operation
Use the ◄ ► arrow keys to select AUPC-Only (default) or AUPC+EDMAC, and then press
ENTER.
Note the following:
•
When AUPC-Only is selected, none of the EDMAC features are available, even though
framing is still enabled.
•
When AUPC+EDMAC is selected, the system further prompts whether to select the
modem as an EDMAC Master or an EDMAC Slave:
(CONFIG: Framing Mode) EDMAC or EDMAC-2: AUPC+EDMAC
EDMAC Mode:
Master
Use the ◄ ► arrow keys to select Master or Slave, and then press ENTER. Note the
following:
•
An EDMAC Master is a unit that is local to the M&C computer, and which passes
messages, via the overhead, to a distant-end modem.
•
An EDMAC Slave is a unit that is not local to the M&C computer; it is located at the
distant-end of a satellite link.
(CONFIG: Framing Mode) EDMAC or EDMAC-2:
AUPC+EDMAC
Distant-end Base Address
0240
To edit the address of the distant-end modem to which this unit will pass messages:
First, use the
keys to edit the value of that digit. The valid range of addresses is from 10 to 9990, in
increments of 10 only.
Note: The the last digit of the address may not be edited; this has been implemented
so that a single Master may pass messages for up to 10 devices at the distant end.
Press ENTER when done.
(CONFIG: Framing Mode) EDMAC or EDMAC-2:
AUPC+EDMAC
Address of this Slave
Unit: 0241
To edit the address of this Slave unit: First, use the
to edit, and then use the
Slave (◄ ►,ENTER)
Master
(◄ ►,▲ ▼,ENTER)
◄ ►
arrow keys to select a digit to edit, and then use the
Slave
(◄ ►,▲ ▼,ENT)
▲ ▼
◄ ►
arrow keys to edit the value of that digit. The valid
5–28
Revision 12
MN/CDM570L.IOM
arrow
▲ ▼
arrow keys to select a digit
