CDM-570/570L Satellite Modem with Optional IP Module
Updating Firmware
Firmware updates are available from Comtech EF Data as follows:
Web Hyperlink
F10805**_V###
F0000358*_v###
N/A
F0000120*_V###
N/A
F0020525*_V###
N/A
F0020522*_V###
N/A
1.
2.
The firmware download files are available from Comtech EF Data in two archive file formats:
*.exe (self extracting) and *.zip (compressed). Some firewalls will not allow downloading of
*.exe files; in this case, download the *.zip file instead. If applicable, one version prior to the
current release is also available for download.
For additional help with "zipped" file types, refer to the help files provided with
the "PKZIP for Windows", "WinZip", or "ZipCentral" file archiving programs.
"PKZIP for DOS" is not supported due to file naming conventions.
To verify the correct firmware number, see Step 1 in the next section of this guide, Sect. 4.3
Preparation for the Base Modem Ethernet FTP Upload Procedure.
EXE/ZIP Filename
FW10805**
FW0000358*
Contact CEFD
FW0000120*
Contact CEFD
FW-0020525*
Contact CEFD
FW-0020522*
Contact CEFD
The Ethernet IP Modules featuring Streamline Encapsulation (IP Module
V1 Firmware Ver. 1.7.# / IP Module V2 Firmware Ver. 2.2.#) are not
compatible with the IP Modules featuring HDLC Encapsulation (IP
Module V1 Firmware Ver. 1.6.# / IP Module V2 Firmware Ver. 2.1.#).
Only the firmware for the CDM-570/570L base modem and Ethernet IP
Modules V1 / V2 without the 3xDES option are available for download
from the CEFD Website.
To obtain the firmwares updates for the CDM-570/570L IP Modules V1 / V2
with the 3xDES option, contact Network Product Customer Support:
Phone: 480.333.2433
E-mail: cdmipsupport@comtechefdata.com.
Contains Image File ('*' or '**' denotes revision letter)
FW10805**.bin – Base modem firmware.
FW-0000358*.bin – IP Module V1 (MPP-50) FW Ver. 1.7.# (and later)
with Streamline Encapsulation, without 3xDES option.
FW-0000355*.bin – IP Module V1 (MPP-50) FW Ver. 1.7.# (and later)
with Streamline Encapsulation, with 3xDES option.
FW-0000120*.bin – IP Module V1 (MPP-50) FW Ver. 1.6.# (and
earlier) with HDLC Encapsulation, without 3xDES option.
FW10875**.bin – IP Module V1 (MPP-50) FW Ver. 1.6.# (and earlier)
with HDLC Encapsulation, with 3xDES option.
FW-0020525*.bin – IP Module V2 (MPP-70) FW Ver. 2.2.# (and later)
with Streamline Encapsulation, without 3xDES option.
FW-0020520*.bin – IP Module V2 (MPP-70) FW Ver. 2.2.# (and later)
with Streamline Encapsulation, with 3xDES option.
FW-0020522*.bin – IP Module V2 (MPP-70) FW Ver. 2.1.# (and
earlier) with HDLC Encapsulation, without 3xDES option.
FW-0020517*.bin – IP Module V2 (MPP-70) FW Ver. 2.1.# (and
earlier) with HDLC Encapsulation, with 3xDES option.
