CDM-570/570L Satellite Modem with Optional IP Module
Ethernet IP Module Interface
o Remote software/firmware upgrade via FTP
•
Configuration Backup and Restore via FTP
•
Event Logging to Capture all IP Module Activity
•
Detailed Statistics of IP traffic
•
IGMP Support for Multicast
•
Static IP Routing for Unicast and Multicast
•
Managed Switch Mode with VLAN Support (added in Firmware Ver. 1.5.4)
•
Streamline Encapsulation (for Ethernet IP Module V1/MPP-50 FW Ver. 1.6.# and later,
or Ethernet IP Module V2/MPP-70 FW Ver. 2.2.# and later).
13.3.1

10/100BaseT Ethernet Interface

In Router Mode operation, the 10/100BaseT Ethernet Interface is used for routing IP traffic to be
transmitted over the satellite or routed to another device on the local LAN. In Managed Switch
Mode, the Ethernet Interface is used to forward IP and non-IP traffic over the satellite. Local or
remote management of all CDM-570/570L and IP Module functions is also available via Telnet,
HTTP, or SNMP.
13.3.2

Network-Based Management

Use any of the following methods to configure, operate, and monitor the CDM-570/570L Satellite
Modem with Optional IP Module:
User Interface
Front Panel
SNMP
HTTP (Web Server)
Serial Command
Line Interface (CLI)
Telnet
Serial Remote
Control
13.3.3

Remote Software/Firmware Upgrade via FTP

The IP Module uses 'flash memory' technology internally. This simplifies firmware updating,
and updates can be obtained over the Internet, through e-mail, or on CD. New firmware can be
Connection
Local - Keypad
Local or remote - Ethernet via
10/100 BaseT Traffic interface
Local or remote - Ethernet via
10/100 BaseT Traffic interface
Local - Serial RS-232 via
Console Port
Local or remote - Ethernet via
10/100 BaseT Traffic interface
Local - Serial RS-232/RS-485
via Remote Control Port
13–2
Modem
IP Module Functions
Functions
IP Address/Subnet
ALL
Mask only
ALL ALL
ALL ALL
ALL ALL
ALL ALL
IP Address/Subnet
ALL
Mask only
Revision 12
MN/CDM570L.IOM
Manual
Reference
Chapter 5
Chapter 6.4
Chapter 13.6
Chapter 14
Chapter 14
Appendix D
