Comtech EF Data CDM-570 Installation And Operation Manual page 361

CDM-570/570L Satellite Modem with Optional IP Module
Appendix D
Command Arguments for
Parameter (Instruction
Type Code and
Qualifier)
Tx Power Level N/A 3 bytes
Increase
Tx Clock Source TCK= 1 byte,
value of 0 thru 2
Tx Data Invert TDI= 1 byte,
value 0 or 1
Tx Frequency TFQ= 9 bytes
Tx Power Level TPL= 4 bytes
Command or
Response to
Query
Query only.
Returns the increase in Tx power level, in dB (from the nominal setting) due to the action
of AUPC.
Range is 0.0 to 9.9 dB
Responds x.x if AUPC is disabled.
Example: PLI=2.3
Command or Query.
Tx Clock Source, where:
0=Internal
1=Tx Terrestrial
2= Loop-Timed
Note: When TCK is changed from Internal to Non-Internal, Clock Extension Mode will be
automatically changed to 0=None if it was 1=TxLock. Reply: TCK+
Example: TCK=0 (selects Internal)
Command or Query.
Invert Transmit Data, where:
0=Normal
1=Inverted
Example: TDI=1 (selects Inverted TX Data)
Command or Query.
Tx Frequency, where:
CDM-570L: 950 to 1950 MHz
CDM-570: 50 to 90 and 100 - 180 MHz
Resolution=100 Hz
Example: TFQ=0950.9872
Example: TFQ=0073.4528
Command or Query.
(Command not valid in AUPC mode)
Tx Output power level, where:
CDM-570L: 0 to -40 dBm (minus sign assumed).
CDM-570: 0 to -25 dBm (minus sign assumed).
Example: TPL=13.4
Description of Arguments
D–11
Revision 12
MN/CDM570L.IOM
Query
Response to
(Instruction Code
Command
and Qualifier)
N/A PLI? PLI=x.x
(see Description of
Arguments)
TCK= TCK? TCK=x
TCK? (see Description of
TCK* Arguments)
TCK#
TDI= TDI? TDI=x
TDI? (see Description of
TDI* Arguments)
TDI#
TFQ= TFQ? TFQ=xxxx.xxxx
TFQ? (see Description of
TFQ* Arguments)
TFQ#
TPL= TPL? TPL=xx.x
TPL? (see Description of
TPL* Arguments)
TPL#
Response to
Query
