CDM-570/570L Satellite Modem with Optional IP Module
Ethernet IP Module Interface
•
VLAN Remote Mode – Use the drop-down menu to Enable or Disable this mode. In this
mode, IP traffic received from the WAN interface will not be forwarded back to the WAN
interface, even though the route table matches.
•
VLAN ID1 through VLAN ID10 – The VLAN ID is a 12-bit field in the Ethernet packet that
contains the IEEE-802.1Q tag. Assign a numeric ID in the range from 0001 to 4094.
Click [Submit] to save changes made to this page.
Each remote modems must have Remote Mode enabled, indicating this is
a distant-end modem.
•
VLAN ID 0001 is reserved and used for normal switch operation.
•
A maximum of 10 VLAN ID matches are supported. Unused VLAN ID
match fields must be set to values that DO NOT match any network
VLAN IDs.
