CDM-570/570L Satellite Modem with Optional IP Module
Ethernet IP Module Interface
13.6.2.6.4

Maint | Reboot

Use this page to initiate the unit reboot process.
After clicking the Reboot hyperlink, the page with the message window as shown opens. To
continue the process, click [Yes, Reboot]. The page then updates as follows:
From here, while the reboot process is underway the page is no longer accessible. During the
reboot process, the CDM-570/570L front panel displays the following messages in succession:
IP OPTION CARD BOOTING.
...PLEASE WAIT
PROCESSOR BOOTING.
...PLEASE WAIT
The reboot process has been completed once the opening screen displays on the modem front
panel:
Comtech CDM-570L Modem
Firmware Version:#.#.#
A new HTTP Interface session may now be initiated as per the procedure outlined in Sect. 13.6.2.

Figure 13-37. Maint | Reboot page

13–64
Revision 12
MN/CDM570L.IOM
