CDM-570/570L Satellite Modem with Optional IP Module
Front Panel Operation
(CONFIG: Remote Control) Ethernet: SNMP
Community
Trap Community: (◄ ►,▲ ▼)
comtech
To edit the SNMP Trap Read or Write Community strings: First, use the
keys to select a character to edit, and then use the
character. Note that only the first 20 characters on the bottom line are available.
All printable ASCII characters are available with the exception of the backslash '/'
(ASCII code 92) and tilde '~' (ASCII code 126).
Press ENTER once the string is composed – all trailing spaces are removed from the
string upon entry.
(CONFIG: Remote Control) Ethernet: SNMP
Version
Trap Version:
SNMPv1
Use the arrow keys to select the SNMP Trap Version (SNMPv1 or SNMPv2), and
then press ENTER.
(CONFIG: Remote Control) Ethernet: SNMP
Addr#1
Trap IP #X:
000.000.000.000
(Where 'X' indicates Trap IP #1 or Trap IP #2) To edit the Trap Destination IP
Address: First, use the ◄ ► arrow keys to select a digit to edit, then use the ▲ ▼
arrow keys to edit the value of that digit.
5.2.2.1.2

CONFIG: All

All = Stop
(Stop, Start)
Use of this menu branch is highly recommended for new users, as it provides guidance through
the modem's configuration in its entirety. Use the ▲ ▼ arrow keys to select between Stop and
Start – the menu then presents every individual configuration option screen in sequential fashion.
For each successive menu, use the ◄ ► arrow keys to first select, and then the ▲ ▼ arrow keys
to edit, the various parameters.
SNMPv2 (◄ ►,ENT)
or
Addr#2
(◄ ►,▲ ▼)
If both Trap IP Addresses are 000.000.000.000, this designates the
Traps as disabled.
(◄ ►,▲ ▼)
5–11
Revision 12
MN/CDM570L.IOM
Traps
◄ ►
arrow keys to edit that
▲ ▼
Traps
Traps IP
