CDM-570/570L Satellite Modem with Optional IP Module
Appendix E
E.5.1

IP Commands and Queries

E.5.1.1 Admin Commands and Queries
Command
Parameter (Instruction
Type Code and
Response to Query
Qualifier)
System Working SWM= 1 byte, value of 0
Mode through 1
Managed Switch EMO= 1 byte, value of 0 or
Multicast Option 1
Header HRR= 3 bytes
Compression
Refresh rate –
UDP/RTP1
Header HRU= 3 bytes
Compression
Refresh rate –UDP
Arguments for
Command or
Command or Query, where:
1=Router-Small Network
2=Router-Large Network
3=Router-Point to Point
4=Router-Vipersat
5=Managed Switch
Router-Vipersat mode needs the ViperSat option to be available on the modem.
Changing the address/working mode may reboot the modem.
Command or Query, where:
0=Disabled
1= Enabled
Enables or disabled forwarding of multicast traffic while in Managed Switch mode.
Valid only when in Managed Switch mode on 570.
Command or Query.
Header compression refresh rate, 1 to 600
Resolution=1 packet
Refresh rate for UDP/RTP1 streams.
Example: HRR=50
Restrictions: 570 only
Command or Query.
Header compression refresh rate, 1 to 600
Resolution=1 packet
Refresh rate for UDP only stream.
Example: HRU =50
Restrictions: 570 only
Description of Arguments
E–9
Revision 12
MN/CDM570L.IOM
Query
Response to
(Instruction Code
Command
and Qualifier)
SWM= SWM? SWM =x
SWM! (see description of
arguments)
EMO = EMO? EMO =x
EMO! (see description of
arguments)
HRR = HRR? HRR =xxx
HRR! (see description of
arguments)
HRU = HRU? HRU =xxx
HRU! (see description of
arguments)
Response to
Query
