CDM-570/570L Satellite Modem with Optional IP Module
Rear Panel Connectors and Pinouts
3.5

Power and Ground Connections

3.5.1 Alternating Current (AC) Power Connector (Standard)

Input Power
Input Voltage
Connector Type
Fuse Protection

3.5.2 Optional Direct Current (DC) Power Connector

3.5.2.1 24 V or 48V DC Units – CDM-570 or CDM-570L Units
Note the following:
Input Power
Input Voltage
Connector Type
Mating Connector
Fuse Protection
A standard, detachable, non-locking, 3-prong power cord (IEC plug)
supplies the Alternating Current (AC) power to the CDM-570 or
CDM-570L units.
Note the following:
AC Power Specifications
40W maximum, 20W typical
100 - 240 volts AC, +6%/-10% - autosensing
(total absolute max. range is 90 - 254 volts AC)
IEC
Use two (2X) 20 mm Slow-Blow fuses for line and neutral fusing – fuses are contained
within a fuse holder that is press-fit into the body of the IEC power module:
•
Use 5.0A fuses for 115 volt AC operation
•
Use 2.5A fuses for 230 volt AC operation
This optional connector supplies the 24V or 48V Direct Current (DC)
power to the CDM-570 or CDM-570L units.
DC Power Specifications
48V
48 watts typical, 55 watts maximum
24V
TBD
48V
48 volts DC nominal (43 volts to 60 volts)
24V
24 volts DC nominal (20 volts to 36 volts)
Corcom PS series
Corcom GA210 or Molex 03-12-1026
Usetwo (2X) 20 mm Slow-Blow fuses for positive and return fusing – fuses are
contained within a fuse holder that is press-fit into the body of the IEC power module:
•
Use T5A fuses for units without a BUC
•
Use T8A fuses for units with a BUC
3–11
Revision 12
MN/CDM570L.IOM
