Deleting Raster Images

Deleting Raster Images
The Manage Images tool lists all raster images in the project, including any rendered images that you have
captured. The tool offers the only way for you to delete an image from the project. You cannot remove an
image from the project by deleting it from a view or a sheet.
To delete a raster image
1 Click Insert tab
2 Select the image name, and click Delete.
3 Click OK when prompted to confirm the deletion.
4 Click OK to close the Manage Images dialog.

Opening Industry Foundation Class (IFC) Files

Revit Architecture opens Industry Foundation Classes (IFC) based on the latest International Alliance for
Interoperability (IAI) IFC 2x3 data exchange standard. (If you open a file that uses an earlier standard [IFC
2x or 2x2], Revit Architecture supports the format and opens it properly.) For information about the IFC file
format, see
When you open an IFC file, Revit Architecture creates a new file based on the default template. For information
about selecting the default template, see
You can load your own IFC class mapping files and override the categories and subcategories for IFC objects.
TIP Make sure you import the geometric data needed for the Revit capability that you plan to use. For more
information, see
To open an IFC file
1 Click
2 In the Open IFC File dialog, navigate to the IFC file to import.
3 Select the IFC file, and click Open.
Revit Architecture creates a new file based on the default template.

Selecting a Template for IFC Files

1 Click
2 In the Import IFC Options dialog, click Browse.
3 In the Browse for Template File dialog, navigate to the desired IFC template file, select it, and
4 In the Import IFC Options dialog, click OK.
on page 1396
on page 1397
Import panel
The Manage Images dialog lists all raster images in the project.
Exporting to Industry Foundation Classes (IFC)
Suitability of Imported Geometry
Open IFC.
Open IFC Options.
click Open.
Manage Images.
on page 1367.
Selecting a Template for IFC Files
on page 1387.
Opening Industry Foundation Class (IFC) Files | 1397
on page 1397.
