RM0033
10.13

ADC registers

Refer to
used in register descriptions.
The peripheral registers must be written at word level (32 bits). Read accesses can be done
by bytes (8 bits), half-words (16 bits) or words (32 bits).
10.13.1

ADC status register (ADC_SR)

Address offset: 0x00
Reset value: 0x0000 0000
31 30 29 28
15 14 13 12
Bits 31:6 Reserved, must be kept at reset value.
Bit 5 OVR: Overrun
Bit 4 STRT: Regular channel start flag
Bit 3 JSTRT: Injected channel start flag
Bit 2 JEOC: Injected channel end of conversion
Bit 1 EOC: Regular channel end of conversion
Bit 0 AWD: Analog watchdog flag
Section 1.1: List of abbreviations for registers
27 26 25
11 10 9
Reserved
This bit is set by hardware when data are lost (either in single mode or in dual/triple mode). It
is cleared by software. Overrun detection is enabled only when DMA = 1 or EOCS = 1.
0: No overrun occurred
1: Overrun has occurred
This bit is set by hardware when regular channel conversion starts. It is cleared by software.
0: No regular channel conversion started
1: Regular channel conversion has started
This bit is set by hardware when injected group conversion starts. It is cleared by software.
0: No injected group conversion started
1: Injected group conversion has started
This bit is set by hardware at the end of the conversion of all injected channels in the group.
It is cleared by software.
0: Conversion is not complete
1: Conversion complete
This bit is set by hardware at the end of the conversion of a regular group of channels. It is
cleared by software or by reading the ADC_DR register.
0: Conversion not complete (EOCS=0), or sequence of conversions not complete (EOCS=1)
1: Conversion complete (EOCS=0), or sequence of conversions complete (EOCS=1)
This bit is set by hardware when the converted voltage crosses the values programmed in
the ADC_LTR and ADC_HTR registers. It is cleared by software.
0: No analog watchdog event occurred
1: Analog watchdog event occurred
24 23 22
Reserved
8 7 6
OVR
rc_w0
RM0033 Rev 8
Analog-to-digital converter (ADC)
for registers for a list of abbreviations
21 20 19 18
5 4 3 2
STRT JSTRT JEOC
rc_w0 rc_w0 rc_w0
17 16
1 0
EOC AWD
rc_w0 rc_w0
