Analog-to-digital converter (ADC)
10.13.3

ADC control register 2 (ADC_CR2)

Address offset: 0x08
Reset value: 0x0000 0000
31 30 29
SWST
EXTEN
ART
reserved
rw rw
15 14 13
reserved
Bit 31 Reserved, must be kept at reset value.
Bit 30 SWSTART: Start conversion of regular channels
Note: This bit can be set only when ADON = 1 otherwise no conversion is launched.
Bits 29:28 EXTEN: External trigger enable for regular channels
Bits 27:24 EXTSEL[3:0]: External event select for regular group
Bit 23 Reserved, must be kept at reset value.
242/1378
28 27 26 25
EXTSEL[3:0]
rw rw rw rw
12 11 10 9
ALIGN EOCS DDS
rw rw rw
This bit is set by software to start conversion and cleared by hardware as soon as the
conversion starts.
0: Reset state
1: Starts conversion of regular channels
These bits are set and cleared by software to select the external trigger polarity and enable
the trigger of a regular group.
00: Trigger detection disabled
01: Trigger detection on the rising edge
10: Trigger detection on the falling edge
11: Trigger detection on both the rising and falling edges
These bits select the external event used to trigger the start of conversion of a regular group:
0000: Timer 1 CC1 event
0001: Timer 1 CC2 event
0010: Timer 1 CC3 event
0011: Timer 2 CC2 event
0100: Timer 2 CC3 event
0101: Timer 2 CC4 event
0110: Timer 2 TRGO event
0111: Timer 3 CC1 event
1000: Timer 3 TRGO event
1001: Timer 4 CC4 event
1010: Timer 5 CC1 event
1011: Timer 5 CC2 event
1100: Timer 5 CC3 event
1101: Timer 8 CC1 event
1110: Timer 8 TRGO event
1111: EXTI line11
24 23 22
JSWST
ART
reserved
rw rw
8 7 6
DMA
rw
RM0033 Rev 8
21 20 19 18
JEXTEN JEXTSEL[3:0]
rw rw rw rw
5 4 3 2
Reserved
RM0033
17 16
rw rw
1 0
CONT ADON
rw rw
