Analog-to-digital converter (ADC)
Note: The software can write to these registers when an ADC conversion is ongoing. The
programmed value will be effective when the next conversion is complete. Writing to this
register is performed with a write delay that can create uncertainty on the effective time at
which the new value is programmed.
10.13.8

ADC watchdog lower threshold register (ADC_LTR)

Address offset: 0x28
Reset value: 0x0000 0000
31 30 29 28
15 14 13 12
Reserved
Bits 31:12 Reserved, must be kept at reset value.
Bits 11:0 LT[11:0]: Analog watchdog lower threshold
Note: The software can write to these registers when an ADC conversion is ongoing. The
programmed value will be effective when the next conversion is complete. Writing to this
register is performed with a write delay that can create uncertainty on the effective time at
which the new value is programmed.
10.13.9

ADC regular sequence register 1 (ADC_SQR1)

Address offset: 0x2C
Reset value: 0x0000 0000
31 30 29
15 14 13
SQ16_0 SQ15[4:0]
rw rw rw
Bits 31:24 Reserved, must be kept at reset value.
Bits 23:20 L[3:0]: Regular channel sequence length
Bits 19:15 SQ16[4:0]: 16th conversion in regular sequence
246/1378
27 26 25
11 10 9
rw rw rw
These bits are written by software to define the lower threshold for the analog watchdog.
28 27 26 25
Reserved
12 11 10 9
rw rw rw rw
These bits are written by software to define the total number of conversions in the regular
channel conversion sequence.
0000: 1 conversion
0001: 2 conversions
...
1111: 16 conversions
These bits are written by software with the channel number (0..18) assigned as the 16th in
the conversion sequence.
24 23 22
Reserved
8 7 6
LT[11:0]
rw rw rw
24 23 22
L[3:0]
rw rw
8 7 6
SQ14[4:0]
rw
RM0033 Rev 8
21 20 19 18
5 4 3 2
rw rw rw rw
21 20 19 18
SQ16[4:1]
rw rw rw rw
5 4 3 2
SQ13[4:0]
rw rw rw
RM0033
17 16
1 0
rw rw
17 16
rw rw
1 0
rw rw
