Cryptographic processor (CRYP)
CRYP_IV1LR (address offset: 0x48)
31 30 29
IV64 IV65 IV66 IV67
rw rw rw
15 14 13
IV80 IV81 IV82 IV83
rw rw rw
CRYP_IV1RR (address offset: 0x4C)
31 30 29
IV96 IV97 IV98 IV99
rw rw rw
15 14 13
IV112 IV113 IV114 IV115
rw rw rw
Note: In DES/3DES modes, only CRYP_IV0(L/R) is used.
Write access to these registers are disregarded when the cryptographic processor is busy
(bit BUSY = 1 in the CRYP_SR register).
19.6.11

CRYP register map
