type (Ethernet Type field) and the IP header version, or when the received frame does not
have enough bytes, as indicated by the IPv4 header's Length field (or when fewer than 20
bytes are available in an IPv4 or IPv6 header). The receive checksum offload also identifies
a TCP, UDP or ICMP payload in the received IP datagrams (IPv4 or IPv6) and calculates the
checksum of such payloads properly, as defined in the TCP, UDP or ICMP specifications. It
includes the TCP/UDP/ICMPv6 pseudo-header bytes for checksum calculation and checks
whether the received checksum field matches the calculated value. The result of this
operation is given as a Payload Checksum Error bit in the receive status word. This status
bit is also set if the length of the TCP, UDP or ICMP payload does not match the expected
payload length given in the IP header. As mentioned in
page 859, the receive checksum offload bypasses the payload of fragmented IP datagrams,
IP datagrams with security features, IPv6 routing headers, and payloads other than TCP,
UDP or ICMP. This information (whether the checksum is bypassed or not) is given in the
receive status, as described in the
configuration, the core does not append any payload checksum bytes to the received
Ethernet frames.
As mentioned in
register bits changes as shown in
Bit 18:
Ethernet frame
0
1
1
1
1
0
0
0
Receive frame controller
If the RA bit is reset in the MAC CSR frame filter register, the MAC performs frame filtering
based on the destination/source address (the application still needs to perform another level
of filtering if it decides not to receive any bad frames like runt, CRC error frames, etc.). On
detecting a filter-fail, the frame is dropped and not transferred to the application. When the
filtering parameters are changed dynamically, and in case of (DA-SA) filter-fail, the rest of
Ethernet (ETH): media access control (MAC) with DMA controller
RDES0: Receive descriptor Word0
RDES0: Receive descriptor Word0 on page
Table

Table 143. Frame statuses

Bit 27: Header Bit 28: Payload
checksum error checksum error
0
0
0
1
1
0
1
1
RM0033 Rev 8
TCP/UDP/ICMP checksum on
897, the meaning of certain
143.
The frame is an IEEE 802.3 frame (Length
0
field value is less than 0x0600).
IPv4/IPv6 Type frame in which no checksum
0
error is detected.
IPv4/IPv6 Type frame in which a payload
1 checksum error (as described for PCE) is
detected
IPv4/IPv6 Type frame in which IP header
0 checksum error (as described for IPCO HCE)
is detected.
IPv4/IPv6 Type frame in which both PCE and
1
IPCO HCE are detected.
IPv4/IPv6 Type frame in which there is no IP
1 HCE and the payload check is bypassed due
to unsupported payload.
Type frame which is neither IPv4 or IPv6
1 (checksum offload bypasses the checksum
check completely)
0 Reserved
section. In this
Frame status
863/1378
