user@host> request chassis sib f2 slot slot-number offline

For more information about the command, see the Junos OS System Basics and

Services Command Reference.

Press and hold the

ONLINE/OFFLINE

the button down until all of the LEDs are not lit.

Release the latch on the ejector handle of the TXP-F2S SIB faceplate.

Flip the ejector handle outward to unseat the TXP-F2S SIB.

Grasp the ejector handle, pull firmly, and slide the TXP-F2S SIB about halfway out of

the chassis.

Place one hand underneath the TXP-F2S SIB to support it and slide it completely out

of the chassis. Place it on the antistatic mat.

CAUTION: Do not stack hardware components on one another after you

remove them. Place each component on an antistatic mat resting on a

stable, flat surface.

Figure 128: Removing a TXP-F2S SIB

Chapter 22: Replacing TX Matrix Plus Hardware Components

button on the the TXP-F2S SIB faceplate. Hold
