TX Matrix Plus Midplane Description

Copyright © 2010, Juniper Networks, Inc.

Figure 3: Rear View of the TX Matrix Plus Router

Air exhaust
TXP-F13
SIBs
Air exhaust
Fan tray 2
Fan tray 3
Air exhaust
TXP-F13
SIBs
PEM 0
Rack Requirements for a TX Matrix Plus Router on page 106
TX Matrix Plus Router Physical Specifications on page 431
TX Matrix Plus Chassis Grounding Specifications on page 440
The midplane is located in the center of the chassis and forms the rear of the TXP-F2
SIB card cage (see Figure 4 on page 12). The TXP-F2S SIBs, TXP-CIPS, TXP-CBs, and
Routing Engines install into the midplane from the front of the chassis, and the TXP-F13
SIBs install into the midplane from the rear of the chassis. The power supplies and cooling
system components also connect to the midplane.
Chapter 2: TX Matrix Plus Hardware Component Overview
ESD point
Fan tray 4
Fan tray 5
Grounding
points
ESD point
PEM 1
11
