Figure 141: ESD Point on Back of the TX Matrix Plus Router
Air exhaust
TXP-F13
SIBs
Air exhaust
Fan tray 2
Fan tray 3
Air exhaust
TXP-F13
SIBs
PEM 0
ESD point
Fan tray 4
Fan tray 5
Grounding
points
ESD point
PEM 1
