TX Matrix Plus Router Hardware Guide
358
Grasp the ejector handles and slide the TXP-CB about halfway out of the chassis.
9.
Place one hand underneath the TXP-CB to support it and slide it completely out of
10.
the chassis. Place it on the antistatic mat.
CAUTION: Do not stack hardware components on one another after you
remove them. Place each component on an antistatic mat resting on a
stable, flat surface.

Figure 122: Removing a TXP-CB
