TX Matrix Plus Installation Safety Guidelines
Related
Documentation
Installation Safety Warnings for M Series, MX Series, and T Series Routers
Copyright © 2010, Juniper Networks, Inc.
Observe the following guidelines before and during router installation:
General Installation Safety Guidelines on page 399
Chassis Lifting Guidelines on page 399
General Installation Safety Guidelines
Before installing the router, verify that the intended site meets the specified power,
environmental, and clearance requirements.
See the following topics:
TX Matrix Plus Clearance Requirements for Airflow and Hardware Maintenance on
page 108
Rack Requirements for a TX Matrix Plus Router on page 106
TX Matrix Plus Router Environmental Specifications on page 433
TX Matrix Plus Router Power Requirements on page 436
TX Matrix Plus Power Distribution on page 439
Chassis Lifting Guidelines
The weight of a fully configured TX Matrix Plus chassis is about 925 lb (420 kg). Observe
the following guidelines for lifting and moving the router:
Do not attempt to manually lift a fully configured TX Matrix Plus router. A mechanical
lift is required to maneuver the router into a rack.
Before using the mechanical lift to move the router, disconnect all external cables.
TX Matrix Plus Switch-Fabric Chassis Description on page 8
Tools Required to Install the TX Matrix Router Using a Lift on page 128
Removing TX Matrix Plus Components Before Installing the Chassis on page 128
Installing the TX Matrix Plus Router Using a Lift on page 138
Reinstalling TX Matrix Plus Components After Installing the Chassis on page 144
Installation Safety Warnings for M Series, MX Series, and T Series Routers on page 399
Observe the following warnings before and during router installation:
Installation Instructions Warning on page 400
Rack-Mounting Requirements and Warnings on page 400
Ramp Warning on page 404
Appendix A: TX Matrix Plus Safety and Regulatory Compliance Information
399
