Upgrading a SIB in an Operational T1600 Router

Copyright © 2010, Juniper Networks, Inc.
On both the TX Matrix Plus router and the T1600 router, verify that upgrade mode
5.
has been set.
user@host# show chassis fabric upgrade-mode
Commit the configuration on both the master and the backup Routing Engines.
6.
user@host# commit synchronize
NOTE: We recommend that you manage the system using a directly attached
management device connected to the
in-band management device connected to the
you access to the system if its control plane is not functioning.
To upgrade a SIB:
Display the status of the T1600 router SIBs by issuing the
1.
user@host> show chassis sibs
Slot State
0 Spare
1 Online
2 Online
3 Online
4 Online
Verify that four SIBs are in the
a SIB online, issue the
request chassis sib online
Attach an electrostatic discharge (ESD) grounding strap to your bare wrist, and connect
2.
the strap to one of the ESD points on the chassis.
Take the spare SIB offline by using one of the following methods:
3.
Press and hold the
ONLINE/OFFLINE
seconds until the
OK
Issue the
request chassis sib offline
user@host> request chassis sib offline slot 0
Replace the spare SIB with a TXP-T1600 SIB. Use the replacement procedure
4.
described in the T1600 Core Router Hardware Guide.
NOTE: After you replace a SIB with a TXP-T1600 SIB, do not replace
another SIB in the T1600 router until you have successfully connected the
TXP-T1600 SIB you just installed and verified operation of that switching
plane.
Chapter 16: Upgrading and Integrating an Operational T1600 Router
CONSOLE
Uptime
255 days, 31 minutes, 12 seconds
255 days, 31 minutes, 12 seconds
255 days, 31 minutes, 12 seconds
255 days, 31 minutes, 12 seconds
255 days, 31 minutes, 12 seconds
Online state and one SIB is in the
operational mode command.
button on the SIB faceplate for about five
LED is not lit.
command. For example:
or AUX ports instead of an
port. This provides
ETHERNET
command:
show chassis sibs
Spare state. To bring
213
