TX Matrix Plus Router Hardware Guide
Related
Documentation
126
Table 35: Mounting Hole Locations for Installing a TX Matrix Plus
Open-Frame Rack Shelf (continued)
Hole Distance Above U Division
21 12.0 in. (30.5 cm)
18 10.25 in. (26.0 cm)
15 8.5 in. (21.6 cm)
12 6.75 in. (17.1 cm)
9 5.0 in. (12.7 cm)
6 3.25 in. (3.8 cm)
Rack Requirements for a TX Matrix Plus Router on page 106
Installing the TX Matrix Plus Mounting Hardware for a Four-Post Rack on page 117
Open-Frame MountingShelf
6.86 U
X
5.86 U
X
4.86 U
X
3.86 U
X
2.86 U
X
1.86 U
X
