TX Matrix Plus Router Hardware Guide
Related
Documentation

TX Matrix Plus DC Power Cable and Cable Lug Specifications

Related
Documentation
438
TX Matrix Plus Power System Description on page 41.
Connecting Power to a Seven-Input 420-A Power Supply on page 167
TX Matrix Plus Power Distribution on page 439
Table 63 on page 438 summarizes the specifications for the power cables that you must
supply.

Table 63: Power Cable Specifications

Cable Type
Quantity and Specification
Power
Eight 4-AWG (21.2 mm
copper conductor, or as required by local
code.
CAUTION: You must ensure that power connections maintain the proper
polarity. The power source cables might be labeled
their polarity. There is no standard color coding for DC power cables. The
color coding used by the external DC power source at your site determines
the color coding for the leads on the power cables that attach to the terminal
studs on each power supply.
CAUTION: Power cables must not block access to TX Matrix Plus components
or drape where people could trip on them.
The accessory box shipped with the TX Matrix Plus router includes the cable lugs that
attach to the terminal studs of each power supply (see Figure 145 on page 440). (The
cable lug shown in Figure 145 on page 440 is also used for the grounding the chassis.)
CAUTION: Before TX Matrix Plus router installation begins, a licensed
electrician must attach a cable lug to the power cables that you supply. A
cable with an incorrectly attached lug can damage the TX Matrix Plus router.
TX Matrix Plus Power System Description on page 41.
Connecting Power to a Seven-Input 420-A Power Supply on page 167
Replacing a DC Power Supply Cable on page 382.
TX Matrix Plus Router Power Requirements on page 436
TX Matrix Plus Power Distribution on page 439
Connector Specification
2
) (minimum)
Cable lug; dual hole, sized to fit
1/4-20 UNC terminal studs at
15.86-mm (0.625-in.) center line.
(+)
Copyright © 2010, Juniper Networks, Inc.
and
to indicate
(–)
