Table 45: Fiber-Optic Array Cable Connections To Lcc 3 - Juniper TX MATRIX PLUS Hardware Manual

Table 45: Fiber-Optic Array Cable Connections to LCC 3 (continued)
T1600 TXP-T1600
router SIB Slot
LCC 3 Slot 1
LCC 3 Slot 1
LCC 3 Slot 1
LCC 3 Slot 1
LCC 3 Slot 2
LCC 3 Slot 2
LCC 3 Slot 2
LCC 3 Slot 2
LCC 3 Slot 3
LCC 3 Slot 3
LCC 3 Slot 3
LCC 3 Slot 3
LCC 3 Slot 4
LCC 3 Slot 4
LCC 3 Slot 4
LCC 3 Slot 4
Copyright © 2010, Juniper Networks, Inc.
Port Cable Labels
A SFC: 0-4-1-A >
3-1-A
B
SFC: 0-4-1-B >
3-1-B
C
SFC: 0-4-1-C >
3-1-C
D
SFC: 0-4-1-D >
3-1-D
A
SFC: 0-7-1-A >
3-2-A
B
SFC: 0-7-1-B >
3-2-B
C
SFC: 0-7-1-C >
3-2-C
D
SFC: 0-7-1-D >
3-2-D
A
SFC: 0-9-1-A >
3-3-A
B SFC: 0-9-1-B >
3-3-B
C SFC: 0-9-1-C >
3-3-C
D SFC: 0-9-1-D >
3-3-D
A SFC: 0-12-1-A >
3-4-A
B
SFC: 0-12-1-B >
3-4-B
C
SFC: 0-12-1-C >
3-4-C
D
SFC: 0-12-1-D >
3-4-D
Chapter 18: Integrating an Offline T1600 Router into a Routing Matrix
LCC: 3-1-A ->
0-4-1-A
LCC: 3-1-B ->
0-4-1-B
LCC: 3-1-C ->
0-4-1-C
LCC: 3-1-D ->
0-4-1-D
LCC: 3-2-A ->
0-7-1-A
LCC: 3-2-B ->
0-7-1-B
LCC: 3-2-C ->
0-7-1-C
LCC: 3-2-D ->
0-7-1-D
LCC: 3-3-A ->
0-9-1-A
LCC: 3-3-B ->
0-9-1-B
LCC: 3-3-C ->
0-9-1-C
LCC: 3-3-D ->
0-9-1-D
LCC: 3-4-A ->
0-12-1-A
LCC: 3-4-B ->
0-12-1-AB
LCC: 3-4-C ->
0-12-1-C
LCC: 3-4-D ->
0-12-1-D
