Verifying That the FPCs on the T1600 Router Are Detected and Online

Purpose
Action
Copyright © 2010, Juniper Networks, Inc.
Link is good on GE port 2 connected to device: LCC1
Speed is 1000Mb
Duplex is full
Autonegotiate is Enabled
Link is good on GE port 4 connected to device: LCC2
Speed is 1000Mb
Duplex is full
Autonegotiate is Enabled
Link is good on GE port 6 connected to device: LCC3
Speed is 1000Mb
Duplex is full
Autonegotiate is Enabled
Link is good on GE port 18 connected to device: SPMB
Speed is 1000Mb
Duplex is full
Autonegotiate is Enabled
Link is good on XE port 26 connected to device: 10GSW
Speed is 10000Mb
Duplex is full
Autonegotiate is Disabled
TX Matrix Plus TXP-CIP Overview on page 36
TX Matrix Plus TXP-CIP LEDs on page 39
Routing Matrix with a TX Matrix Plus Router System Control Plane Architecture on
page 56
Control Plane Connections from the TX Matrix Plus Router to the T1600 Routers on
page 58
Troubleshooting the TX Matrix Plus TXP-CIPs on page 309
After the T1600 router has booted, verify the state of the FPCs.
To verify that all FPCs in the T1600 router are detected and online:
Issue the
1. show chassis hardware
router are detected. For example:
user@host> show chassis hardware lcc 0
lcc0-re1:
--------------------------------------------------------------------------
Hardware inventory:
Item
Chassis
Midplane
FPM GBUS
FPM Display
CIP
PEM 0 Rev 07
Chapter 19: Verifying the State of the TX Matrix Plus and T1600 Router
command to verify that all the FPCs in the T1600
Version Part number Serial number
JN1103199AHA
REV 03 710-017247 RC3765
REV 10 710-002901 DR1407
REV 01 710-021387 DN5441
REV 06 710-002895 DP6021
740-017906 UA26384
Description
T1600
T Series Backplane
T640 FPM Board
T1600 FPM Display
T Series CIP
Power Entry Module
