TX Matrix Plus Router Hardware Guide
338
Install a dust cover on each of the removed cable connectors. Align the dust cover
5.
with the cable connector and carefully press them together until they stop. The cover
and the cable connector are keyed to ensure proper mating.
Remove the fiber-optic array cable. If the cable is greater than 10 m long, we
6.
recommend that you reinstall the pulling-eye assembly on one end of the cable to
facilitate pulling the cable through the raceway.
Installing a Fiber-Optic Array Cable
NOTE: You must use the same length for every fiber-optic array cable from
a particular T1600 router to the TX Matrix Plus router. However, you do not
need to use the same length for all fiber-optic array cables within a routing
matrix.
Using the supplied label sheets, attach a label to each end of the replacement
1.
fiber-optic array cable to help you identify the corresponding TXP-F13 SIB connector
and TXP-T1600 SIB.
Make sure that the port is offline.
2.
WARNING: Do not look directly into a fiber-optic array port or a connector
at the end of a fiber-optic array cable attached to a fiber-optic array port.
The fiber optics emit laser light that can damage your eyes.
Route the end of the fiber-optic array cable that plugs into the TXP-F13 SIB over the
3.
TX Matrix Plus router to the TXP-F13 SIB.
Remove the dust covers from the fiber-optic array cable connectors. Store the dust
4.
covers in a dust-free resealable plastic bag.
Clean the port and cable.
5.
Align the fiber-optic array cable with the corresponding TXP-F13 SIB port and carefully
6.
press it into the port until it stops. The cable connector and port are keyed to ensure
proper mating.
NOTE: The optics in a fiber-optic array port are spring loaded, so you must
continue to apply force to a fiber-optic array cable or loopback connector
while securing it to a TXP-F13 SIB or TXP-T1600 SIB.
Pull the latch for the cable management clamp (Figure 82 on page 190) toward you
7.
to release it.
Place the fiber-optic array cable upward into the labeled slot
8.
cable. Route the cable upward toward the comb assembly on top of the chassis Figure
83 on page 191).
A
,
B
,
C
, or
D
for that
Copyright © 2010, Juniper Networks, Inc.
