TX Matrix Plus Router Hardware Guide

Connecting a Switching Plane in an Operational T1600 Router

214
NOTE: Do not bring the SIB online until instructed to do so.
Issue the
5. show chassis alarms
user@host> show chassis alarms
5 alarms currently active
Alarm time
2009-05-06 17:33:53 PDT
2009-05-06 17:33:51 PDT
2009-05-06 17:33:49 PDT
2009-05-06 17:33:49 PDT
2009-05-06 17:31:58 PDT
The fiber-optic array cables should already be connected to the TXP-F13 SIBs on the TX
Matrix Plus router. This procedure connects the fiber-optic array cables to the TXP-T1600
SIBs in the T1600 router (four for each TXP-T1600 SIB). To connect the switching planes:
Attach an electrostatic discharge (ESD) grounding strap to your bare wrist, and connect
1.
the strap to one of the ESD points on the chassis.
Use the labels on the ends of the fiber-optic array cables and Table 41 on page 217 to
2.
identify the cable that plugs into the fiber-optic array ports labeled
Remove the dust cover from the fiber-optic array ports on the TXP-T1600 SIB. Store
3.
the dust cover in a dust-free resealable plastic bag.
Remove the dust covers from the four fiber-optic array cable connectors that connect
4.
to one TXP-T1600 SIB. Store the dust covers in a dust-free resealable plastic bag.
Clean the four fiber-optic array cable connectors.
5.
Align the cable connectors labeled
6.
array port, and carefully press each cable connector into the port until it stops. The
cable connectors and fiber-optic array ports are keyed to ensure proper mating.
Optionally, you can route the cables into the rear cable management system. Pull the
7.
latch for the cable management clamp toward you to release it. Place the fiber-optic
array cable upward into one the cable slots. Route the cable upward toward the top
of the chassis, and press it into the divider.
CAUTION: You must maintain a minimum bend radius of 4 in. (10.2 cm)
short term, and 3 in. (7.6 cm) long term.
Arrange the fiber-optic array cables so that they do not interfere with system airflow
8.
and maintenance access.
Bring the TXP-T1600 online by using one of the following methods:
9.
Press and hold the
ONLINE/OFFLINE
seconds until the
OK
command to display all alarms in the router.
Class Description
Minor Check SIB 0
Major SIB_L - Fan Revision mismatch
Minor SIB 0 Fbr Bndls
Minor SIB 0 LOL
Minor PEM 1 Absent
, , , and with the corresponding fiber-optic
A B C D
button on the SIB faceplate for about five
LED is lit.
, , , and
A B C
Copyright © 2010, Juniper Networks, Inc.
.
D
